- cable could keep your car parked far away from the power location .No more need to shuffle cars in and out of the garage for charging.
- HIGH QUALITY - High strength material, which has better quality and can be used for longer;
- waterproof could be safer during charging.
- our charger have better conductivity and could prevent overheating.
- charging cables go through a meticulous and thorough evaluation to ensure EXCELLENT PERFORMANCE, top-tier quality, and long-lasting construction.
Electric ParametersRated Voltage480V (3 Phase) ACRated Current (Power)32A 3 Phase, 22KWFrequency50/60HzInsulation Resistance> 1000MTerminal Temperature Rise<;50KWithstand Voltage2000VContact Resistance0.5mItem Length10M/32.8ftMechanical PerformanceMechaincal Life>1000 times no-load plug in/ offCoupled Insertion Force45N-100NWithstand ImpactDropping from a 1 m- height and running- over by a 2T vehicle.MaterialEnclosureThermoplastic, flame retardant grade UL94 V-0Cable MaterialTPUTerminalCopper alloy, silver platingPlug TypeEV PlugIEC 62196 type 2 female plugEVSE PlugIEC 62196 type 2 male plugEnvironmentWork Temperature-30 50Work Humidity5% 95%Work Altitude<;2000mSafety and WarrantyIngress ProtectionIP54Certification StandardIEC 62196-1/ IEC 62196-2PackageDimension(L/W/H)40*40*10(CM)GW6KGPacking ListEV Cable * 1; User manual* 1Real PicturesTIPSAttention: Beforepaying,youmustchoosethe correct plugtype (type1ortype2).It'sveryimportant.CAUTION:1. Don't submerge the EV charging box in water.2. Don't step on, fold or knot the cable.3. Don't drop the EV charging box or place a heavy object on it.4. Don't place the charging cable near high temperature object when charging.5. Don't operate the EVSE in temperatures beyond its operating range of -25C to 55C.6. Power-supply side input cable should be at least 3*2.5mm(recommended 3*4mm), with a standard 16A scoket. It is suggested taht the power distribution is done by the professionals.7.Don't put fingers into the charging connector when the power plug is still connecting to the power.8. Don't use this EV charging box when the cable is damaged.9. Don't use this device with an extension c
